Product description
This is Overhead Crane With Lower Rotating Electromagnetic Beam.
It is especially applicable to lift material of different specifications and which needs horizontal rotation. The spacing of electromagnet can be adjusted electrically and magnetic force of electromagnet can be adjusted through infinitely variable control according to the specifications(different thickness，length and pieces, etc.）and weight of the lifted material. The followings can be supplied according to the user’s requirements: speed governing(1：10 or larger)of the mechanisms，overload&warning，remote control，PLC control，failure detection, display, record and printing system, etc. (the data below is used for indoor)．
Main Specifications
Technical Parameter
Structure
Overhead Crane With Lower Rotating Electromagnetic Beam | |||||
Capacity(t) | Span(m) | Lifting height(m) | Lifting speed(m/min) | Working duty | Turn round(r/min) |
15 | 34.3 | 5.5 | 12.2 | A6 | 1 |
25 | 46.3 | 5 | 11.8 | A6 | 1 |
30 | 53.3 | 5 | 12 | A6 | 1 |
Case
Application
The overhead crane has slewing telescopic electromagnetic carrier-beam is applicable to the fixed span at indoors or outdoors of steel mill, shipyard, port, yard and storage, etc. It is used for loading, unloading and carrying steel plate, profile steel, and spool etc.
