Double Girder Semi-gantry Crane with Hook (MGB)

The double girder semi-gantry crane with hook is mainly composed of gantry, crane crab, trolley travelling mechanism and electric control system.
The gantry with a box-shape structure, which has a leg at its one side and runs along the ground rails. It has no leg at the other side and runs along the rails on the factory workshop.

Availability:

Quantity:



Inquire

Product Description

Product description

The double girder semi-gantry crane with hook is mainly composed of gantry, crane crab, trolley travelling mechanism and electric control system.

The gantry with a box-shape structure, which has a leg at its one side and runs along the ground rails. It has no leg at the other side and runs along the rails on the factory workshop.

This crane adopts closed cab, which are adjustable seat, insulating mat on the floor, toughened glass for the window, fire extinguisher, electric tan and auxiliary equipment, such as air conditioner, acoustic alarm and interphone which can be furnished as required by users.

The rest structure and configuration are the same as the MG double-girder gantry crane.

Technical Parameter

Double Girder Semi-gantry Crane with Hook (MGB)
Capacity ton	Span m	Lifting height m	Lifting speed m/min	Trolley speed m/min	Crane speed m/min	Working class	Track
3	12	6~9	8, 8/0.8	20	20	A3-A5	P34 P38
	16
	20
	24
5	12	6~9	8, 8/0.8	20	20	A3-A5	P24 P38
	16
	20
	24
	30	9
10	12	6~9	7, 7/0.7	20	20	A3-A5	P38 P43
	16
	20
	24
	30	9
16	12	6~9	3.5, 3.5/0.35	20	20	A3-A5	P38 P43
	16
	20
	24
	30	9
