Double Girder Hook-Type Gantry Crane

Key Features:

·Heavy-duty dual girder construction for superior load capacity

·Standard hook lifting mechanism for versatile material handling

·Designed for industrial applications requiring high lifting precision

Structural Configuration:

Primary Components:

• Portal frame with double girders

• Hook lifting trolley system

• Gantry travel mechanism

• Operator cabin

• Electrical control system

Available Configurations:

Girder Options:

·Box-type construction (for maximum durability)

·Truss-type construction (for lightweight applications)

Leg Designs:

1. A-frame configuration (enhanced stability)

2. U-frame configuration (wider span capability)

Operational Specifications:

·Lifting Capacity: 5-500 tons (customizable)

·Span: 10-50 meters (adjustable to requirements)

·Working Class: A5-A8 (depending on usage intensity)

Safety & Control Features:

·Overload protection system

·Limit switches for precise positioning

·Emergency stop function

·Optional remote control operation

Power Supply Options:

·Standard: Cable reel system

·Alternative: Overhead conductor system

Optional Accessories:

·Anti-sway control system

·Load moment indicator

·Variable frequency drive for smooth operation

·Weather protection packages
